Step1: Product
Semtech Corporation SX1239IMLTRT
Image shown is a representation only
Manufacturer
Manufacturer No
SX1239IMLTRT
Quantity
41
Availability
In Stock
Package
24-VQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
RF RX FSK/GFSK 433/868MHZ 24QFN
Detailed Description
TrueRF™ RF Receiver FSK, GFSK, GMSK, MSK, OOK 433MHz, 868MHz, 915MHz -120dBm 300kbps PCB, Surface Mount 24-QFN (5x5)
DataSheet
Series
TrueRF™
Frequency
433MHz, 868MHz, 915MHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Part Status
Active
Sensitivity
-120dBm
Applications
AMR, Home Automation, Security
Manufacturer
Semtech Corporation
Mounting Type
Surface Mount
Data Interface
PCB, Surface Mount
Package / Case
24-VQFN Exposed Pad
Data Rate (Max)
300kbps
Voltage - Supply
1.8V ~ 3.6V
Antenna Connector
PCB, Surface Mount
Base Product Number
SX1239
Current - Receiving
16mA
Operating Temperature
-40°C ~ 85°C
Modulation or Protocol
FSK, GFSK, GMSK, MSK, OOK
Supplier Device Package
24-QFN (5x5)
| Attribute | Value |
|---|---|
| Series | TrueRF™ |
| Frequency | 433MHz, 868MHz, 915MHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Part Status | Active |
| Sensitivity | -120dBm |
| Applications | AMR, Home Automation, Security |
| Manufacturer | Semtech Corporation |
| Mounting Type | Surface Mount |
| Data Interface | PCB, Surface Mount |
| Package / Case | 24-VQFN Exposed Pad |
| Data Rate (Max) | 300kbps |
| Voltage - Supply | 1.8V ~ 3.6V |
| Antenna Connector | PCB, Surface Mount |
| Base Product Number | SX1239 |
| Current - Receiving | 16mA |
| Operating Temperature | -40°C ~ 85°C |
| Modulation or Protocol | FSK, GFSK, GMSK, MSK, OOK |
| Supplier Device Package | 24-QFN (5x5) |
