Step1: Product
Sanyo SH2141-5511
Image shown is a representation only
Manufacturer
Manufacturer No
SH2141-5511
Packaging
Bulk
Description
STPR MTR BIPOLAR 6.3V 0.3A/PHASE
Detailed Description
Bipolar Stepper Motor Hybrid, Dual Shaft Frame Size 200.0 Step 300 mA 24VDC
DataSheet
Mfr
Sanyo
Type
Hybrid, Dual Shaft
Series
SH
Coil Type
Bipolar
Packaging
Bulk
Step Angle
1.8°
Part Status
Active
Rotor Inertia
0.58gcm²
Approval Agency
CE, cURus, TUV
Coil Resistance
21 Ohms
Voltage - Rated
24VDC
Diameter - Shaft
0.157" (4.00mm)
Size / Dimension
Square - 0.551" x 0.551" (14.00mm x 14.00mm)
Termination Style
Wire Leads
Steps per Revolution
200.0
Current Rating (Amps)
300 mA
Mounting Hole Spacing
0.453" (11.50mm)
Operating Temperature
-10°C ~ 50°C
Length - Shaft and Bearing
0.591" (15.00mm)
Torque - Holding (oz-in / mNm)
0.92 / 6.5
| Attribute | Value |
|---|---|
| Mfr | Sanyo |
| Type | Hybrid, Dual Shaft |
| Series | SH |
| Coil Type | Bipolar |
| Packaging | Bulk |
| Step Angle | 1.8° |
| Part Status | Active |
| Rotor Inertia | 0.58gcm² |
| Approval Agency | CE, cURus, TUV |
| Coil Resistance | 21 Ohms |
| Voltage - Rated | 24VDC |
| Diameter - Shaft | 0.157" (4.00mm) |
| Size / Dimension | Square - 0.551" x 0.551" (14.00mm x 14.00mm) |
| Termination Style | Wire Leads |
| Steps per Revolution | 200.0 |
| Current Rating (Amps) | 300 mA |
| Mounting Hole Spacing | 0.453" (11.50mm) |
| Operating Temperature | -10°C ~ 50°C |
| Length - Shaft and Bearing | 0.591" (15.00mm) |
| Torque - Holding (oz-in / mNm) | 0.92 / 6.5 |
