Step1: Product
Preci-Dip 8FM-78-0009-02-146
Image shown is a representation only
Manufacturer
Manufacturer No
8FM-78-0009-02-146
Packaging
Bulk
Description
CONN SOCKET 9P 0.1 GOLD SMD R/A
Detailed Description
9 Position Socket Connector 0.100" (2.54mm) Surface Mount, Right Angle Gold
DataSheet
Mfr
Preci-Dip
Style
Board to Board
Series
8FM
Packaging
Bulk
Part Status
Active
Termination
Solder
Contact Type
Female Socket
Contact Shape
Circular
Mounting Type
Surface Mount, Right Angle
Connector Type
Socket
Fastening Type
Push-Pull
Number of Rows
1
Pitch - Mating
0.100" (2.54mm)
Contact Material
Beryllium Copper
Insulation Color
Black
Insulation Height
0.096" (2.44mm)
Base Product Number
8FM-78
Insulation Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Number of Positions
9
Contact Finish - Post
Tin
Current Rating (Amps)
3A
Operating Temperature
-55°C ~ 125°C
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Mating
Flash
| Attribute | Value |
|---|---|
| Mfr | Preci-Dip |
| Style | Board to Board |
| Series | 8FM |
| Packaging | Bulk |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Female Socket |
| Contact Shape | Circular |
| Mounting Type | Surface Mount, Right Angle |
| Connector Type | Socket |
| Fastening Type | Push-Pull |
| Number of Rows | 1 |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Material | Beryllium Copper |
| Insulation Color | Black |
| Insulation Height | 0.096" (2.44mm) |
| Base Product Number | 8FM-78 |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled |
| Number of Positions | 9 |
| Contact Finish - Post | Tin |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 125°C |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | Flash |
