onsemi NCP1236BD65R2G
Image shown is a representation only
Manufacturer
Manufacturer No
NCP1236BD65R2G
Quantity
3848
Availability
In Stock
Package
8-SOIC (0.154", 3.90mm Width), 7 Leads
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC OFFLINE SWITCH FLYBACK 7SOIC
Detailed Description
Converter Offline Flyback Topology 65kHz 7-SOIC
DataSheet
Topology
Flyback
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Duty Cycle
80%
Part Status
Active
Manufacturer
onsemi
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.154", 3.90mm Width), 7 Leads
Fault Protection
Over Load, Over Power, Over Temperature, Over Voltage
Output Isolation
Isolated
Internal Switch(s)
No
Voltage - Start Up
12 V
Base Product Number
NCP1236
Frequency - Switching
65kHz
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
7-SOIC
Voltage - Supply (Vcc/Vdd)
9.5V ~ 28V
| Attribute | Value |
|---|---|
| Topology | Flyback |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Duty Cycle | 80% |
| Part Status | Active |
| Manufacturer | onsemi |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width), 7 Leads |
| Fault Protection | Over Load, Over Power, Over Temperature, Over Voltage |
| Output Isolation | Isolated |
| Internal Switch(s) | No |
| Voltage - Start Up | 12 V |
| Base Product Number | NCP1236 |
| Frequency - Switching | 65kHz |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 7-SOIC |
| Voltage - Supply (Vcc/Vdd) | 9.5V ~ 28V |
