NXP USA Inc. NX5P2924DUKZ
Image shown is a representation only
Manufacturer
Manufacturer No
NX5P2924DUKZ
Quantity
91
Availability
In Stock
Package
6-XFBGA, WLCSP
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
LOGIC-CONTROLLED HIGH-SIDE POWER
Detailed Description
Low RdsON logic-controlled high-side load switch, 2.5A @ 5.5V
DataSheet
Mfr
NXP USA Inc.
Interface
On/Off
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Input Type
Inverting
Output Type
N-Channel
Part Status
Active
Switch Type
General Purpose
Rds On (Typ)
18mOhm
Mounting Type
Surface Mount
Package / Case
6-XFBGA, WLCSP
Voltage - Load
0.8V ~ 5.5V
Number of Outputs
1
Output Configuration
High Side
Ratio - Input:Output
1:1
Operating Temperature
-40°C ~ 85°C (TA)
Current - Output (Max)
2.5A
Supplier Device Package
6-WLCSP (1.39x0.89)
Voltage - Supply (Vcc/Vdd)
Not Required
| Attribute | Value |
|---|---|
| Mfr | NXP USA Inc. |
| Interface | On/Off |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Input Type | Inverting |
| Output Type | N-Channel |
| Part Status | Active |
| Switch Type | General Purpose |
| Rds On (Typ) | 18mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 6-XFBGA, WLCSP |
| Voltage - Load | 0.8V ~ 5.5V |
| Number of Outputs | 1 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Current - Output (Max) | 2.5A |
| Supplier Device Package | 6-WLCSP (1.39x0.89) |
| Voltage - Supply (Vcc/Vdd) | Not Required |
