NXP USA Inc. JN5139-001-M/04R1T
Image shown is a representation only
Manufacturer
Manufacturer No
JN5139-001-M/04R1T
Package
Module
Packaging
Tape & Reel (TR)
Description
RF TXRX MODULE 802.15.4U.FL SMD
Detailed Description
802.15.4 Zigbee® Transceiver Module 2.4GHz Antenna Not Included, U.FL Surface Mount
DataSheet
Mfr
NXP USA Inc.
Series
JN5139-001-M0xR
Protocol
Zigbee®
Frequency
2.4GHz
Packaging
Tape & Reel (TR)
Memory Size
192kB ROM, 96kB RAM
Part Status
Obsolete
Sensitivity
-100dBm
Antenna Type
Antenna Not Included, U.FL
Mounting Type
Surface Mount
Package / Case
Module
Power - Output
19dBm
Voltage - Supply
2.2V ~ 3.6V
Serial Interfaces
I2C, SPI, UART
RF Family/Standard
802.15.4
Base Product Number
JN513
Current - Receiving
45mA
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 85°C
Current - Transmitting
125mA
| Attribute | Value |
|---|---|
| Mfr | NXP USA Inc. |
| Series | JN5139-001-M0xR |
| Protocol | Zigbee® |
| Frequency | 2.4GHz |
| Packaging | Tape & Reel (TR) |
| Memory Size | 192kB ROM, 96kB RAM |
| Part Status | Obsolete |
| Sensitivity | -100dBm |
| Antenna Type | Antenna Not Included, U.FL |
| Mounting Type | Surface Mount |
| Package / Case | Module |
| Power - Output | 19dBm |
| Voltage - Supply | 2.2V ~ 3.6V |
| Serial Interfaces | I2C, SPI, UART |
| RF Family/Standard | 802.15.4 |
| Base Product Number | JN513 |
| Current - Receiving | 45mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 85°C |
| Current - Transmitting | 125mA |
