Monolithic Power Systems Inc. MP8040DN-LF-P
Image shown is a representation only
Manufacturer
Manufacturer No
MP8040DN-LF-P
Package
8-SOIC (0.154", 3.90mm Width) Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC HALF BRIDGE DRIVER 4.5A 8SOIC
Detailed Description
Half Bridge Driver DC Motors, DC-DC Converters NMOS 8-SOIC-EP
DataSheet
Features
Bootstrap Circuit, Status Flag
Interface
Logic
Load Type
Capacitive and Resistive
Packaging
Tape & Reel (TR)
Technology
NMOS
Part Status
Active
Applications
DC Motors, DC-DC Converters
Manufacturer
Monolithic Power Systems Inc.
Rds On (Typ)
100mOhm
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.154", 3.90mm Width) Exposed Pad
Voltage - Load
7.5V ~ 25V
Fault Protection
Current Limiting, Over Temperature, UVLO
Voltage - Supply
7.5V ~ 25V
Output Configuration
Half Bridge
Current - Peak Output
9A
Operating Temperature
-40°C ~ 85°C
Supplier Device Package
8-SOIC-EP
Current - Output / Channel
4.5A
| Attribute | Value |
|---|---|
| Features | Bootstrap Circuit, Status Flag |
| Interface | Logic |
| Load Type | Capacitive and Resistive |
| Packaging | Tape & Reel (TR) |
| Technology | NMOS |
| Part Status | Active |
| Applications | DC Motors, DC-DC Converters |
| Manufacturer | Monolithic Power Systems Inc. |
| Rds On (Typ) | 100mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) Exposed Pad |
| Voltage - Load | 7.5V ~ 25V |
| Fault Protection | Current Limiting, Over Temperature, UVLO |
| Voltage - Supply | 7.5V ~ 25V |
| Output Configuration | Half Bridge |
| Current - Peak Output | 9A |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 8-SOIC-EP |
| Current - Output / Channel | 4.5A |
