Step1: Product
Molex 0357491460
Image shown is a representation only
Manufacturer
Manufacturer No
0357491460
Packaging
Bulk
Description
SPADE TERM 357491460
Detailed Description
5,6 Stud Spade Terminal Connector Crimp 18-20 AWG
DataSheet
Series
35749
Packaging
Bulk
Insulation
Non-Insulated
Wire Gauge
18-20 AWG
Part Status
Obsolete
Termination
Crimp
Manufacturer
Molex
Mounting Type
Free Hanging (In-Line)
Stud/Tab Size
5,6 Stud
Terminal Type
Standard
Contact Finish
Tin
Contact Material
Brass
Length - Overall
0.811" (20.60mm)
Base Product Number
035749
Insulation Diameter
0.126" (3.20mm)
Width - Outer Edges
0.240" (6.10mm)
Length - Termination
0.291" (7.40mm)
Tongue Inside Opening
0.134" (3.40mm)
Length - Ring Center to Termination
0.205" (5.20mm)
| Attribute | Value |
|---|---|
| Series | 35749 |
| Packaging | Bulk |
| Insulation | Non-Insulated |
| Wire Gauge | 18-20 AWG |
| Part Status | Obsolete |
| Termination | Crimp |
| Manufacturer | Molex |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 5,6 Stud |
| Terminal Type | Standard |
| Contact Finish | Tin |
| Contact Material | Brass |
| Length - Overall | 0.811" (20.60mm) |
| Base Product Number | 035749 |
| Insulation Diameter | 0.126" (3.20mm) |
| Width - Outer Edges | 0.240" (6.10mm) |
| Length - Termination | 0.291" (7.40mm) |
| Tongue Inside Opening | 0.134" (3.40mm) |
| Length - Ring Center to Termination | 0.205" (5.20mm) |
