Step1: Product
Microsemi Corporation MSTC110-08
Image shown is a representation only
Manufacturer
Manufacturer No
MSTC110-08
Package
Module
Packaging
Bulk
Description
SCR MODULE 800V MODULE
Detailed Description
SCR Module 800 V Series Connection - All SCRs Chassis Mount Module
Datasheet
Packaging
Bulk
Structure
Series Connection - All SCRs
Manufacturer
Microsemi Corporation
Mounting Type
Chassis Mount
Package / Case
Module
Voltage - Off State
800 V
Operating Temperature
-40°C ~ 130°C (TJ)
Number of SCRs, Diodes
2 SCRs
Current - Hold (Ih) (Max)
250 mA
Current - Gate Trigger (Igt) (Max)
150 mA
Current - On State (It (AV)) (Max)
110 A
Voltage - Gate Trigger (Vgt) (Max)
3 V
Current - Non Rep. Surge 50, 60Hz (Itsm)
2250A @ 50Hz
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Structure | Series Connection - All SCRs |
| Manufacturer | Microsemi Corporation |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Voltage - Off State | 800 V |
| Operating Temperature | -40°C ~ 130°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs |
| Current - Hold (Ih) (Max) | 250 mA |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - On State (It (AV)) (Max) | 110 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 2250A @ 50Hz |
