Step1: Product
Microchip Technology DSC6003CA3B-PROG
Image shown is a representation only
Manufacturer
Manufacturer No
DSC6003CA3B-PROG
Package
4-VDFN
Packaging
Tube
Description
ONE-TIME-PROGRAMMABLE ULTRA-LOW
Detailed Description
XO (Standard) CMOS 2 kHz ~ 80 MHz Programmable Oscillator 1.71V ~ 3.63V Enable/Disable 4-VDFN
DataSheet
Type
XO (Standard)
Output
CMOS
Series
DSC60XXB
Function
Enable/Disable
Packaging
Tube
Part Status
Active
Manufacturer
Microchip Technology
Mounting Type
Surface Mount
Base Resonator
MEMS
Package / Case
4-VDFN
Size / Dimension
0.126" L x 0.098" W (3.20mm x 2.50mm)
Voltage - Supply
1.71V ~ 3.63V
Programmable Type
Blank (User Must Program)
Base Product Number
DSC6003
Frequency Stability
±20ppm
Height - Seated (Max)
0.035" (0.90mm)
Operating Temperature
-40°C ~ 125°C
Current - Supply (Max)
1.3mA (Typ)
Supplier Device Package
4-VDFN (3.2x2.5)
Available Frequency Range
2 kHz ~ 80 MHz
| Attribute | Value |
|---|---|
| Type | XO (Standard) |
| Output | CMOS |
| Series | DSC60XXB |
| Function | Enable/Disable |
| Packaging | Tube |
| Part Status | Active |
| Manufacturer | Microchip Technology |
| Mounting Type | Surface Mount |
| Base Resonator | MEMS |
| Package / Case | 4-VDFN |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Voltage - Supply | 1.71V ~ 3.63V |
| Programmable Type | Blank (User Must Program) |
| Base Product Number | DSC6003 |
| Frequency Stability | ±20ppm |
| Height - Seated (Max) | 0.035" (0.90mm) |
| Operating Temperature | -40°C ~ 125°C |
| Current - Supply (Max) | 1.3mA (Typ) |
| Supplier Device Package | 4-VDFN (3.2x2.5) |
| Available Frequency Range | 2 kHz ~ 80 MHz |
