Step1: Product
KYOCERA AVX PC201FKN6
Image shown is a representation only
Manufacturer
Manufacturer No
PC201FKN6
Package
Module
Packaging
Bulk
Description
DIODE MODULE GP 600V 200A MODULE
Detailed Description
Diode Array 1 Pair Series Connection 600 V 200A Chassis Mount Module
DataSheet
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Packaging
Bulk
Technology
Standard
Part Status
Obsolete
Manufacturer
KYOCERA AVX
Mounting Type
Chassis Mount
Package / Case
Module
Base Product Number
PC201
Diode Configuration
1 Pair Series Connection
Supplier Device Package
Module
Reverse Recovery Time (trr)
110 ns
Current - Reverse Leakage @ Vr
10 mA @ 600 V
Voltage - DC Reverse (Vr) (Max)
600 V
Operating Temperature - Junction
-40°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If
1.4 V @ 200 A
Current - Average Rectified (Io) (per Diode)
200A
| Attribute | Value |
|---|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Packaging | Bulk |
| Technology | Standard |
| Part Status | Obsolete |
| Manufacturer | KYOCERA AVX |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Base Product Number | PC201 |
| Diode Configuration | 1 Pair Series Connection |
| Supplier Device Package | Module |
| Reverse Recovery Time (trr) | 110 ns |
| Current - Reverse Leakage @ Vr | 10 mA @ 600 V |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1.4 V @ 200 A |
| Current - Average Rectified (Io) (per Diode) | 200A |
