KYOCERA AVX 009090055116861+
Image shown is a representation only
Manufacturer
Manufacturer No
009090055116861+
Packaging
Bag
Description
WIRE TO BOARD
Detailed Description
5 Position Receptacle Connector 0.250" (6.35mm) Through Hole Gold
DataSheet
Mfr
KYOCERA AVX
Style
Board to Cable/Wire
Series
9090, Kyocera
Packaging
Bag
Part Status
Active
Termination
Solder
Contact Type
Female Socket
Contact Shape
Circular
Mounting Type
Through Hole
Connector Type
Receptacle
Fastening Type
Locking Ramp
Number of Rows
1
Pitch - Mating
0.250" (6.35mm)
Voltage Rating
600VAC
Contact Material
Copper Alloy
Insulation Color
Brown
Insulation Height
0.551" (14.00mm)
Base Product Number
009090
Insulation Material
Thermoplastic
Number of Positions
5
Contact Finish - Post
Tin
Contact Length - Post
0.146" (3.70mm)
Operating Temperature
-55°C ~ 105°C
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Mating
10.0µin (0.25µm)
