Step1: Product
Kingbright AP3216F3C
Image shown is a representation only
Manufacturer
Manufacturer No
AP3216F3C
Package
2-SMD, No Lead
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
3.2X1.6MM IR SMD EMITTER
Detailed Description
Infrared (IR) Emitter 940nm 1.2V 50mA 1.2mW/sr @ 50mA 160° 2-SMD, No Lead
DataSheet
Type
Infrared (IR)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Wavelength
940nm
Orientation
Top View
Part Status
Active
Manufacturer
Kingbright
Mounting Type
Surface Mount, Right Angle
Viewing Angle
160°
Package / Case
2-SMD, No Lead
Operating Temperature
-40°C ~ 85°C
Voltage - Forward (Vf) (Typ)
1.2V
Current - DC Forward (If) (Max)
50mA
Radiant Intensity (Ie) Min @ If
1.2mW/sr @ 50mA
| Attribute | Value |
|---|---|
| Type | Infrared (IR) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Wavelength | 940nm |
| Orientation | Top View |
| Part Status | Active |
| Manufacturer | Kingbright |
| Mounting Type | Surface Mount, Right Angle |
| Viewing Angle | 160° |
| Package / Case | 2-SMD, No Lead |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50mA |
| Radiant Intensity (Ie) Min @ If | 1.2mW/sr @ 50mA |
