IXYS IXYN110N120A4
Image shown is a representation only
Manufacturer
Manufacturer No
IXYN110N120A4
Quantity
3
Availability
In Stock
Package
SOT-227-4, miniBLOC
Packaging
Tube
Description
IGBT PT 1200V 275A SOT-227B
Detailed Description
IGBT PT 1200 V 275 A 830 W Chassis Mount SOT-227B
DataSheet
Series
XPT™, GenX4™
IGBT Type
PT
Packaging
Tube
Input Type
Standard
Gate Charge
305 nC
Part Status
Active
Power - Max
830 W
Manufacturer
IXYS
Mounting Type
Chassis Mount
Package / Case
SOT-227-4, miniBLOC
Test Condition
600V, 50A, 2Ohm, 15V
Switching Energy
2.5mJ (on), 8.4mJ (off)
Base Product Number
IXYN110
Td (on/off) @ 25°C
42ns/550ns
Operating Temperature
-55°C ~ 175°C (TJ)
Supplier Device Package
SOT-227B
Vce(on) (Max) @ Vge, Ic
1.8V @ 15V, 110A
Current - Collector (Ic) (Max)
275 A
Current - Collector Pulsed (Icm)
950 A
Voltage - Collector Emitter Breakdown (Max)
1200 V
| Attribute | Value |
|---|---|
| Series | XPT™, GenX4™ |
| IGBT Type | PT |
| Packaging | Tube |
| Input Type | Standard |
| Gate Charge | 305 nC |
| Part Status | Active |
| Power - Max | 830 W |
| Manufacturer | IXYS |
| Mounting Type | Chassis Mount |
| Package / Case | SOT-227-4, miniBLOC |
| Test Condition | 600V, 50A, 2Ohm, 15V |
| Switching Energy | 2.5mJ (on), 8.4mJ (off) |
| Base Product Number | IXYN110 |
| Td (on/off) @ 25°C | 42ns/550ns |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Supplier Device Package | SOT-227B |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 110A |
| Current - Collector (Ic) (Max) | 275 A |
| Current - Collector Pulsed (Icm) | 950 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
