Step1: Product
Infineon Technologies D2450N02TXPSA1
Image shown is a representation only
Manufacturer
Manufacturer No
D2450N02TXPSA1
Package
DO-200AB, B-PUK
Packaging
Tray
Description
DIODE STANDARD 200V 2450A
Detailed Description
Diode 200 V 2450A Clamp On
DataSheet
Mfr
Infineon Technologies
Speed
Standard Recovery >500ns, > 200mA (Io)
Packaging
Tray
Technology
Standard
Part Status
Obsolete
Mounting Type
Clamp On
Package / Case
DO-200AB, B-PUK
Base Product Number
D2450N02
Current - Reverse Leakage @ Vr
50 mA @ 200 V
Voltage - DC Reverse (Vr) (Max)
200 V
Current - Average Rectified (Io)
2450A
Operating Temperature - Junction
-40°C ~ 180°C
Voltage - Forward (Vf) (Max) @ If
880 mV @ 2000 A
| Attribute | Value |
|---|---|
| Mfr | Infineon Technologies |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Packaging | Tray |
| Technology | Standard |
| Part Status | Obsolete |
| Mounting Type | Clamp On |
| Package / Case | DO-200AB, B-PUK |
| Base Product Number | D2450N02 |
| Current - Reverse Leakage @ Vr | 50 mA @ 200 V |
| Voltage - DC Reverse (Vr) (Max) | 200 V |
| Current - Average Rectified (Io) | 2450A |
| Operating Temperature - Junction | -40°C ~ 180°C |
| Voltage - Forward (Vf) (Max) @ If | 880 mV @ 2000 A |
