Ignion NN01-103
Image shown is a representation only
Manufacturer
Manufacturer No
NN01-103
Packaging
Tape & Reel (TR)
Description
GEOFIND - 103
Detailed Description
RF ANTENNA Beidou, GLONASS, GPS Chip Solder Surface Mount
DataSheet
Gain
1.4dBi, 1.2dBi, 1.3dBi
VSWR
2
Series
Geofind™
Packaging
Tape & Reel (TR)
Part Status
Obsolete
Termination
Solder
Antenna Type
Chip
Applications
Beidou, GLONASS, GPS
Height (Max)
0.035" (0.90mm)
Manufacturer
Ignion
Mounting Type
Surface Mount
Frequency Group
UHF (1GHz ~ 2GHz)
Frequency Range
1.598GHz ~ 1.606GHz
Number of Bands
3
RF Family/Standard
Navigation
Base Product Number
NN01
Frequency (Center/Band)
1.561GHz, 1.575GHz, 1.602GHz
| Attribute | Value |
|---|---|
| Gain | 1.4dBi, 1.2dBi, 1.3dBi |
| VSWR | 2 |
| Series | Geofind™ |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Termination | Solder |
| Antenna Type | Chip |
| Applications | Beidou, GLONASS, GPS |
| Height (Max) | 0.035" (0.90mm) |
| Manufacturer | Ignion |
| Mounting Type | Surface Mount |
| Frequency Group | UHF (1GHz ~ 2GHz) |
| Frequency Range | 1.598GHz ~ 1.606GHz |
| Number of Bands | 3 |
| RF Family/Standard | Navigation |
| Base Product Number | NN01 |
| Frequency (Center/Band) | 1.561GHz, 1.575GHz, 1.602GHz |
