Step1: Product
I-PEX 20566-001E-01
Image shown is a representation only
Manufacturer
Manufacturer No
20566-001E-01
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MHF 5 RECEPTACLE
Detailed Description
I-PEX MHF5 Connector Receptacle, Male Pin 50 Ohms Surface Mount Solder
DataSheet
Mfr
I-PEX
Series
MHF® 5
Impedance
50 Ohms
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Part Status
Active
Housing Color
Black
Mounting Type
Surface Mount
Connector Type
Receptacle, Male Pin
Fastening Type
Snap-On
Connector Style
I-PEX MHF5
Frequency - Max
12 GHz
Number of Ports
1
Shield Termination
Solder
Contact Termination
Solder
Operating Temperature
-40°C ~ 90°C
Center Contact Material
Brass
| Attribute | Value |
|---|---|
| Mfr | I-PEX |
| Series | MHF® 5 |
| Impedance | 50 Ohms |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Part Status | Active |
| Housing Color | Black |
| Mounting Type | Surface Mount |
| Connector Type | Receptacle, Male Pin |
| Fastening Type | Snap-On |
| Connector Style | I-PEX MHF5 |
| Frequency - Max | 12 GHz |
| Number of Ports | 1 |
| Shield Termination | Solder |
| Contact Termination | Solder |
| Operating Temperature | -40°C ~ 90°C |
| Center Contact Material | Brass |
