Step1: Product
Hirose Electric Co Ltd DG23-C3AA
Image shown is a representation only
Manufacturer
Manufacturer No
DG23-C3AA
Packaging
Bag
Description
LIMIT SWTICH
Detailed Description
Switch SPDT Through Hole
DataSheet
Series
DG
Circuit
SPDT
Packaging
Bag
Pretravel
0.020" (0.5mm)
Overtravel
0.008" (0.2mm)
Part Status
Last Time Buy
Manufacturer
Hirose Electric Co Ltd
Actuator Type
Round (Pin Plunger)
Mounting Type
Through Hole
Electrical Life
200,000 Cycles
Mechanical Life
1,000,000 Cycles
Operating Force
75gf
Switch Function
On-Mom
Termination Style
PC Pin
Ingress Protection
IP40
Operating Position
0.213" (5.4mm)
Base Product Number
DG23-C3
Differential Travel
0.004" (0.1mm)
Voltage Rating - DC
30 V
Current Rating (Amps)
50mA (DC)
Operating Temperature
-25°C ~ 85°C
| Attribute | Value |
|---|---|
| Series | DG |
| Circuit | SPDT |
| Packaging | Bag |
| Pretravel | 0.020" (0.5mm) |
| Overtravel | 0.008" (0.2mm) |
| Part Status | Last Time Buy |
| Manufacturer | Hirose Electric Co Ltd |
| Actuator Type | Round (Pin Plunger) |
| Mounting Type | Through Hole |
| Electrical Life | 200,000 Cycles |
| Mechanical Life | 1,000,000 Cycles |
| Operating Force | 75gf |
| Switch Function | On-Mom |
| Termination Style | PC Pin |
| Ingress Protection | IP40 |
| Operating Position | 0.213" (5.4mm) |
| Base Product Number | DG23-C3 |
| Differential Travel | 0.004" (0.1mm) |
| Voltage Rating - DC | 30 V |
| Current Rating (Amps) | 50mA (DC) |
| Operating Temperature | -25°C ~ 85°C |
