Harwin Inc. M22-5330605R
Image shown is a representation only
Manufacturer
Manufacturer No
M22-5330605R
Quantity
4750
Availability
In Stock
Packaging
Tape & Reel (TR)
Description
CONN HDR 2MM 6POS
Detailed Description
Connector Header Surface Mount, Right Angle 6 position 0.079" (2.00mm)
DataSheet
Mfr
Harwin Inc.
Style
Board to Board or Cable
Series
M22
Packaging
Tape & Reel (TR)
Shrouding
Unshrouded
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Square
Mounting Type
Surface Mount, Right Angle
Connector Type
Header, Cuttable
Fastening Type
Push-Pull
Number of Rows
1
Pitch - Mating
0.079" (2.00mm)
Contact Material
Brass
Insulation Color
Black
Insulation Height
0.079" (2.00mm)
Base Product Number
M22-533
Insulation Material
Polyamide (PA9T), Nylon 9T
Number of Positions
6
Contact Finish - Post
Gold
Current Rating (Amps)
2A
Operating Temperature
-40°C ~ 105°C
Contact Finish - Mating
Gold
Contact Length - Mating
0.165" (4.20mm)
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
Flash
Contact Finish Thickness - Mating
Flash
| Attribute | Value |
|---|---|
| Mfr | Harwin Inc. |
| Style | Board to Board or Cable |
| Series | M22 |
| Packaging | Tape & Reel (TR) |
| Shrouding | Unshrouded |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Mounting Type | Surface Mount, Right Angle |
| Connector Type | Header, Cuttable |
| Fastening Type | Push-Pull |
| Number of Rows | 1 |
| Pitch - Mating | 0.079" (2.00mm) |
| Contact Material | Brass |
| Insulation Color | Black |
| Insulation Height | 0.079" (2.00mm) |
| Base Product Number | M22-533 |
| Insulation Material | Polyamide (PA9T), Nylon 9T |
| Number of Positions | 6 |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 2A |
| Operating Temperature | -40°C ~ 105°C |
| Contact Finish - Mating | Gold |
| Contact Length - Mating | 0.165" (4.20mm) |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | Flash |
