Diodes Incorporated DGD05473FNQ-7
Image shown is a representation only
Manufacturer
Manufacturer No
DGD05473FNQ-7
Quantity
41
Availability
In Stock
Package
10-UFDFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC GATE DRV HALF-BRDG DFN3030-10
Detailed Description
Half-Bridge Gate Driver IC CMOS/TTL U-DFN3030-10
DataSheet
Grade
Automotive
Gate Type
MOSFET (N-Channel)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Input Type
CMOS/TTL
Part Status
Obsolete
Channel Type
Independent
Manufacturer
Diodes Incorporated
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
10-UFDFN Exposed Pad
Voltage - Supply
4.7V ~ 14V
Number of Drivers
2
Base Product Number
DGD05473
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Operating Temperature
150°C (TJ)
Rise / Fall Time (Typ)
16ns, 12ns
Supplier Device Package
U-DFN3030-10
Logic Voltage - VIL, VIH
0.8V, 2.4V
High Side Voltage - Max (Bootstrap)
50 V
Current - Peak Output (Source, Sink)
1.5A, 2.5A
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Gate Type | MOSFET (N-Channel) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Input Type | CMOS/TTL |
| Part Status | Obsolete |
| Channel Type | Independent |
| Manufacturer | Diodes Incorporated |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 10-UFDFN Exposed Pad |
| Voltage - Supply | 4.7V ~ 14V |
| Number of Drivers | 2 |
| Base Product Number | DGD05473 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | 150°C (TJ) |
| Rise / Fall Time (Typ) | 16ns, 12ns |
| Supplier Device Package | U-DFN3030-10 |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| High Side Voltage - Max (Bootstrap) | 50 V |
| Current - Peak Output (Source, Sink) | 1.5A, 2.5A |
