Diodes Incorporated DGD05463M10-13
Image shown is a representation only
Manufacturer
Manufacturer No
DGD05463M10-13
Quantity
542
Availability
In Stock
Package
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC GATE DRVR HALF-BRIDGE 10MSOP
Detailed Description
Half-Bridge Gate Driver IC Non-Inverting 10-MSOP
DataSheet
Gate Type
MOSFET (N-Channel)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Input Type
Non-Inverting
Part Status
Obsolete
Channel Type
Synchronous
Manufacturer
Diodes Incorporated
Mounting Type
Surface Mount
Package / Case
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Voltage - Supply
4.5V ~ 14V
Number of Drivers
2
Base Product Number
DGD05463
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Operating Temperature
-40°C ~ 150°C (TJ)
Rise / Fall Time (Typ)
17ns, 12ns
Supplier Device Package
10-MSOP
Logic Voltage - VIL, VIH
0.8V, 2.4V
High Side Voltage - Max (Bootstrap)
50 V
Current - Peak Output (Source, Sink)
1.5A, 2.5A
| Attribute | Value |
|---|---|
| Gate Type | MOSFET (N-Channel) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Input Type | Non-Inverting |
| Part Status | Obsolete |
| Channel Type | Synchronous |
| Manufacturer | Diodes Incorporated |
| Mounting Type | Surface Mount |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Voltage - Supply | 4.5V ~ 14V |
| Number of Drivers | 2 |
| Base Product Number | DGD05463 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rise / Fall Time (Typ) | 17ns, 12ns |
| Supplier Device Package | 10-MSOP |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| High Side Voltage - Max (Bootstrap) | 50 V |
| Current - Peak Output (Source, Sink) | 1.5A, 2.5A |
