Step1: Product
Cornell Dubilier Knowles PPC123M010FG2SAA
Image shown is a representation only
Manufacturer
Manufacturer No
PPC123M010FG2SAA
Package
FlatPack, Tabbed
Packaging
Box
Description
CAP ALUM POLY 12000UF 20% 10V
Detailed Description
12000 µF 10 V Aluminum - Polymer Capacitors FlatPack, Tabbed 6mOhm 2000 Hrs @ 125°C
DataSheet
Type
Polymer
Series
PPC
Packaging
Box
Tolerance
±20%
Capacitance
12000 µF
Part Status
Obsolete
Applications
General Purpose
Manufacturer
Cornell Dubilier Knowles
Mounting Type
Chassis Mount
Package / Case
FlatPack, Tabbed
Voltage - Rated
10 V
Lifetime @ Temp.
2000 Hrs @ 125°C
Size / Dimension
6.250" L x 5.000" W (158.75mm x 127.00mm)
Height - Seated (Max)
0.039" (1.00mm)
Operating Temperature
-55°C ~ 125°C
Ripple Current @ Low Frequency
16 A @ 120 Hz
Ripple Current @ High Frequency
18 A @ 20 kHz
ESR (Equivalent Series Resistance)
6mOhm
| Attribute | Value |
|---|---|
| Type | Polymer |
| Series | PPC |
| Packaging | Box |
| Tolerance | ±20% |
| Capacitance | 12000 µF |
| Part Status | Obsolete |
| Applications | General Purpose |
| Manufacturer | Cornell Dubilier Knowles |
| Mounting Type | Chassis Mount |
| Package / Case | FlatPack, Tabbed |
| Voltage - Rated | 10 V |
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
| Size / Dimension | 6.250" L x 5.000" W (158.75mm x 127.00mm) |
| Height - Seated (Max) | 0.039" (1.00mm) |
| Operating Temperature | -55°C ~ 125°C |
| Ripple Current @ Low Frequency | 16 A @ 120 Hz |
| Ripple Current @ High Frequency | 18 A @ 20 kHz |
| ESR (Equivalent Series Resistance) | 6mOhm |
