Step1: Product
Cornell Dubilier Knowles 206K050CS4G-FA
Image shown is a representation only
Manufacturer
Manufacturer No
206K050CS4G-FA
Package
18-SMD, Gull Wing
Packaging
Tube
Description
CAP FILM 20UF 10% 50VDC 18SMD
Detailed Description
20 µF Film Capacitor 50V Polyester, Metallized 18-SMD, Gull Wing
Mfr
Cornell Dubilier Knowles
Series
Capstick® CS
Features
Low ESR, Low ESL
Packaging
Tube
Tolerance
±10%
Capacitance
20 µF
Part Status
Active
Termination
Gull Wing
Applications
DC Link, DC Filtering; High Frequency, Switching
Lead Spacing
0.394" (10.00mm)
Mounting Type
Surface Mount
Package / Case
18-SMD, Gull Wing
Size / Dimension
1.150" L x 0.500" W (29.20mm x 12.70mm)
Dielectric Material
Polyester, Metallized
Voltage Rating - DC
50V
Height - Seated (Max)
0.379" (9.62mm)
Operating Temperature
-55°C ~ 125°C
ESR (Equivalent Series Resistance)
2.5 mOhms
| Attribute | Value |
|---|---|
| Mfr | Cornell Dubilier Knowles |
| Series | Capstick® CS |
| Features | Low ESR, Low ESL |
| Packaging | Tube |
| Tolerance | ±10% |
| Capacitance | 20 µF |
| Part Status | Active |
| Termination | Gull Wing |
| Applications | DC Link, DC Filtering; High Frequency, Switching |
| Lead Spacing | 0.394" (10.00mm) |
| Mounting Type | Surface Mount |
| Package / Case | 18-SMD, Gull Wing |
| Size / Dimension | 1.150" L x 0.500" W (29.20mm x 12.70mm) |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - DC | 50V |
| Height - Seated (Max) | 0.379" (9.62mm) |
| Operating Temperature | -55°C ~ 125°C |
| ESR (Equivalent Series Resistance) | 2.5 mOhms |
