Step1: Product
CML Micro MMA-005022B
Image shown is a representation only
Manufacturer
Manufacturer No
MMA-005022B
Package
Die
Packaging
Case
Description
IC RF AMP GPS 30KHZ-50GHZ DIE
Detailed Description
RF Amplifier IC General Purpose 30kHz ~ 50GHz Die
DataSheet
Gain
15.5dB
P1dB
22dBm
RF Type
General Purpose
Frequency
30kHz ~ 50GHz
Packaging
Case
Part Status
Active
Manufacturer
CML Micro
Noise Figure
9dB
Mounting Type
Surface Mount
Package / Case
Die
Test Frequency
20GHz
Current - Supply
210mA
Voltage - Supply
7V
Base Product Number
MMA-005022
Supplier Device Package
Die
| Attribute | Value |
|---|---|
| Gain | 15.5dB |
| P1dB | 22dBm |
| RF Type | General Purpose |
| Frequency | 30kHz ~ 50GHz |
| Packaging | Case |
| Part Status | Active |
| Manufacturer | CML Micro |
| Noise Figure | 9dB |
| Mounting Type | Surface Mount |
| Package / Case | Die |
| Test Frequency | 20GHz |
| Current - Supply | 210mA |
| Voltage - Supply | 7V |
| Base Product Number | MMA-005022 |
| Supplier Device Package | Die |
