Step1: Product
CEL 2SA1978-A
Image shown is a representation only
Manufacturer
Manufacturer No
2SA1978-A
Package
TO-236-3, SC-59, SOT-23-3
Packaging
Strip
Description
RF TRANS PNP 12V 5.5GHZ
Detailed Description
RF Transistor PNP 12V 50mA 5.5GHz 200mW Surface Mount
DataSheet
Gain
10dB
Packaging
Strip
Part Status
Obsolete
Power - Max
200mW
Manufacturer
CEL
Mounting Type
Surface Mount
Package / Case
TO-236-3, SC-59, SOT-23-3
Transistor Type
PNP
Operating Temperature
150°C (TJ)
Frequency - Transition
5.5GHz
Noise Figure (dB Typ @ f)
2dB @ 1GHz
Current - Collector (Ic) (Max)
50mA
DC Current Gain (hFE) (Min) @ Ic, Vce
20 @ 15mA, 10V
Voltage - Collector Emitter Breakdown (Max)
12V
| Attribute | Value |
|---|---|
| Gain | 10dB |
| Packaging | Strip |
| Part Status | Obsolete |
| Power - Max | 200mW |
| Manufacturer | CEL |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Transistor Type | PNP |
| Operating Temperature | 150°C (TJ) |
| Frequency - Transition | 5.5GHz |
| Noise Figure (dB Typ @ f) | 2dB @ 1GHz |
| Current - Collector (Ic) (Max) | 50mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 15mA, 10V |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
