Step1: Product
Antenova A10472
Image shown is a representation only
Manufacturer
Manufacturer No
A10472
Packaging
Tape & Reel (TR)
Description
ANTENNA 868/015MHZ KIRBII SMD
Detailed Description
RF ANTENNA ISM, LoRa, Sigfox Chip Solder Surface Mount
DataSheet
Gain
-1.8dBi, -1.6dBi
VSWR
1.2, 2.1
Packaging
Tape & Reel (TR)
Part Status
Obsolete
Return Loss
-20dB, -10dB
Termination
Solder
Antenna Type
Chip
Applications
ISM, LoRa, Sigfox
Height (Max)
0.126" (3.40mm)
Manufacturer
Antenova
Mounting Type
Surface Mount
Frequency Group
UHF (300MHz ~ 1GHz)
Frequency Range
868MHz ~ 870MHz, 902MHz ~ 928MHz
Number of Bands
2
RF Family/Standard
General ISM
Frequency (Center/Band)
868MHz, 915MHz
| Attribute | Value |
|---|---|
| Gain | -1.8dBi, -1.6dBi |
| VSWR | 1.2, 2.1 |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Return Loss | -20dB, -10dB |
| Termination | Solder |
| Antenna Type | Chip |
| Applications | ISM, LoRa, Sigfox |
| Height (Max) | 0.126" (3.40mm) |
| Manufacturer | Antenova |
| Mounting Type | Surface Mount |
| Frequency Group | UHF (300MHz ~ 1GHz) |
| Frequency Range | 868MHz ~ 870MHz, 902MHz ~ 928MHz |
| Number of Bands | 2 |
| RF Family/Standard | General ISM |
| Frequency (Center/Band) | 868MHz, 915MHz |
