Analog Power Inc. AM7966N
Image shown is a representation only
Manufacturer
Manufacturer No
AM7966N
Package
8-PowerVDFN
Packaging
Bulk
Description
MOSFET 2N-CH 60V 6.8A DFN5X6
Detailed Description
Mosfet Array 60V 6.8A (Ta), 19A (Tc) 2.5W (Ta), 19W (Tc) Surface Mount 8-DFN (5x6)
DataSheet
Packaging
Bulk
Technology
MOSFET (Metal Oxide)
Part Status
Active
Power - Max
2.5W (Ta), 19W (Tc)
Manufacturer
Analog Power Inc.
Configuration
2 N-Channel (Dual)
Mounting Type
Surface Mount
Package / Case
8-PowerVDFN
Vgs(th) (Max) @ Id
1V @ 250µA
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
37mOhm @ 4A, 10V
Supplier Device Package
8-DFN (5x6)
Gate Charge (Qg) (Max) @ Vgs
8nC @ 4.5V
Drain to Source Voltage (Vdss)
60V
Input Capacitance (Ciss) (Max) @ Vds
854pF @ 15V
Current - Continuous Drain (Id) @ 25°C
6.8A (Ta), 19A (Tc)
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Power - Max | 2.5W (Ta), 19W (Tc) |
| Manufacturer | Analog Power Inc. |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVDFN |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 37mOhm @ 4A, 10V |
| Supplier Device Package | 8-DFN (5x6) |
| Gate Charge (Qg) (Max) @ Vgs | 8nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 854pF @ 15V |
| Current - Continuous Drain (Id) @ 25°C | 6.8A (Ta), 19A (Tc) |
