Step1: Product
Amphenol ICC (Commercial Products) L17HTNES4R2C
Image shown is a representation only
Manufacturer
Manufacturer No
L17HTNES4R2C
Quantity
1,080
Availability
In Stock
Packaging
Tray
Description
CONN D-SUB RCPT 9POS R/A SOLDER
Detailed Description
9 Position D-Sub Receptacle, Female Sockets Connector
Datasheet
Mfr
Amphenol ICC (Commercial Products)
Color
Black
Series
HTN
Features
Board Lock
Packaging
Tray
Termination
Solder
Contact Form
Stamped
Contact Type
Signal
Mounting Type
Through Hole, Right Angle
Connector Type
Receptacle, Female Sockets
Contact Finish
Gold
Flange Feature
Board Side (4-40)
Number of Rows
2
Voltage Rating
600V
Backset Spacing
0.318" (8.08mm)
Connector Style
D-Sub
Contact Material
Copper Alloy
Base Product Number
L17HTNES4
Dielectric Material
Thermoplastic, Glass Filled
Number of Positions
9
Current Rating (Amps)
5A
Operating Temperature
-55°C ~ 150°C
Shell Material, Finish
Steel, Tin-Nickel Plated
Contact Finish Thickness
15.0µin (0.38µm)
Material Flammability Rating
UL94 V-0
Shell Size, Connector Layout
1 (DE, E)
| Attribute | Value |
|---|---|
| Mfr | Amphenol ICC (Commercial Products) |
| Color | Black |
| Series | HTN |
| Features | Board Lock |
| Packaging | Tray |
| Termination | Solder |
| Contact Form | Stamped |
| Contact Type | Signal |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Board Side (4-40) |
| Number of Rows | 2 |
| Voltage Rating | 600V |
| Backset Spacing | 0.318" (8.08mm) |
| Connector Style | D-Sub |
| Contact Material | Copper Alloy |
| Base Product Number | L17HTNES4 |
| Dielectric Material | Thermoplastic, Glass Filled |
| Number of Positions | 9 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -55°C ~ 150°C |
| Shell Material, Finish | Steel, Tin-Nickel Plated |
| Contact Finish Thickness | 15.0µin (0.38µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 1 (DE, E) |
