Ai-Thinker PB-01
Image shown is a representation only
Manufacturer
Manufacturer No
PB-01
Package
20-SMD Module
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
RF TXRX MOD BT PCB TH SMD
Detailed Description
Bluetooth Bluetooth v5.0 Transceiver Module 2.4GHz PCB Trace Surface Mount
DataSheet
Mfr
Ai-Thinker
Protocol
Bluetooth v5.0
Frequency
2.4GHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Memory Size
138kB SRAM
Part Status
Active
Sensitivity
-93dBm
Antenna Type
PCB Trace
Mounting Type
Surface Mount
Package / Case
20-SMD Module
Power - Output
10dBm
Voltage - Supply
2.7V ~ 3.6V
Serial Interfaces
ADC, GPIO, PWM, SPI
RF Family/Standard
Bluetooth
Utilized IC / Part
PHY6212
Current - Receiving
7mA
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 85°C
Current - Transmitting
25mA
| Attribute | Value |
|---|---|
| Mfr | Ai-Thinker |
| Protocol | Bluetooth v5.0 |
| Frequency | 2.4GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Memory Size | 138kB SRAM |
| Part Status | Active |
| Sensitivity | -93dBm |
| Antenna Type | PCB Trace |
| Mounting Type | Surface Mount |
| Package / Case | 20-SMD Module |
| Power - Output | 10dBm |
| Voltage - Supply | 2.7V ~ 3.6V |
| Serial Interfaces | ADC, GPIO, PWM, SPI |
| RF Family/Standard | Bluetooth |
| Utilized IC / Part | PHY6212 |
| Current - Receiving | 7mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 85°C |
| Current - Transmitting | 25mA |
