Step1: Product
Ymin MPD470M1DD15040R
Image shown is a representation only
Manufacturer
Manufacturer No
MPD470M1DD15040R
Package
2917 (7343 Metric)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
CAP ALUM 20V POLAR
Detailed Description
47 µF 20 V Aluminum - Polymer Capacitors 2917 (7343 Metric) 40mOhm 2000 Hrs @ 105°C
DataSheet
Series
MPD15
Impedance
40 mOhms
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Tolerance
±20%
Capacitance
47 µF
Part Status
Active
Applications
General Purpose
Manufacturer
Ymin
Mounting Type
Surface Mount
Package / Case
2917 (7343 Metric)
Voltage - Rated
20 V
Lifetime @ Temp.
2000 Hrs @ 105°C
Size / Dimension
0.287" L x 0.169" W (7.30mm x 4.30mm)
Height - Seated (Max)
0.059" (1.50mm)
Operating Temperature
-55°C ~ 105°C
Ripple Current @ Low Frequency
320 mA @ 120 Hz
Ripple Current @ High Frequency
3.2 A @ 100 kHz
ESR (Equivalent Series Resistance)
40mOhm
| Attribute | Value |
|---|---|
| Series | MPD15 |
| Impedance | 40 mOhms |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Tolerance | ±20% |
| Capacitance | 47 µF |
| Part Status | Active |
| Applications | General Purpose |
| Manufacturer | Ymin |
| Mounting Type | Surface Mount |
| Package / Case | 2917 (7343 Metric) |
| Voltage - Rated | 20 V |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Size / Dimension | 0.287" L x 0.169" W (7.30mm x 4.30mm) |
| Height - Seated (Max) | 0.059" (1.50mm) |
| Operating Temperature | -55°C ~ 105°C |
| Ripple Current @ Low Frequency | 320 mA @ 120 Hz |
| Ripple Current @ High Frequency | 3.2 A @ 100 kHz |
| ESR (Equivalent Series Resistance) | 40mOhm |
