Step1: Product
Wolfspeed, Inc. E3D30065D
Image shown is a representation only
Manufacturer
Manufacturer No
E3D30065D
Package
TO-247-3
Packaging
Tube
Description
DIODE ARRAY SIC 650V 42A TO247-3
Detailed Description
Diode Array 1 Pair Common Anode 650 V 42A Through Hole TO-247-3
DataSheet
Grade
Automotive
Speed
No Recovery Time > 500mA (Io)
Series
E-Series
Packaging
Tube
Technology
SiC (Silicon Carbide) Schottky
Part Status
Obsolete
Manufacturer
Wolfspeed, Inc.
Mounting Type
Through Hole
Package / Case
TO-247-3
Base Product Number
E3D30065
Diode Configuration
1 Pair Common Anode
Supplier Device Package
TO-247-3
Reverse Recovery Time (trr)
0 ns
Current - Reverse Leakage @ Vr
95 µA @ 650 V
Voltage - DC Reverse (Vr) (Max)
650 V
Operating Temperature - Junction
-55°C ~ 175°C
Voltage - Forward (Vf) (Max) @ If
1.8 V @ 16 A
Current - Average Rectified (Io) (per Diode)
42A
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Speed | No Recovery Time > 500mA (Io) |
| Series | E-Series |
| Packaging | Tube |
| Technology | SiC (Silicon Carbide) Schottky |
| Part Status | Obsolete |
| Manufacturer | Wolfspeed, Inc. |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Base Product Number | E3D30065 |
| Diode Configuration | 1 Pair Common Anode |
| Supplier Device Package | TO-247-3 |
| Reverse Recovery Time (trr) | 0 ns |
| Current - Reverse Leakage @ Vr | 95 µA @ 650 V |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - Forward (Vf) (Max) @ If | 1.8 V @ 16 A |
| Current - Average Rectified (Io) (per Diode) | 42A |
