Vishay General Semiconductor - Diodes Division VS-ST1000C22K0
Image shown is a representation only
Manufacturer
Manufacturer No
VS-ST1000C22K0
Package
TO-200AC, K-PUK, A-24
Packaging
Bulk
Description
SCR 2.2KV 2913A A-24 (K-PUK)
Detailed Description
SCR 2.2 kV 2913 A Standard Recovery Clamp On A-24 (K-Puk)
DataSheet
SCR Type
Standard Recovery
Packaging
Bulk
Part Status
Obsolete
Manufacturer
Vishay General Semiconductor - Diodes Division
Mounting Type
Clamp On
Package / Case
TO-200AC, K-PUK, A-24
Base Product Number
ST1000
Voltage - Off State
2.2 kV
Operating Temperature
-40°C ~ 125°C
Supplier Device Package
A-24 (K-Puk)
Current - Hold (Ih) (Max)
600 mA
Current - Off State (Max)
100 mA
Voltage - On State (Vtm) (Max)
1.8 V
Current - Gate Trigger (Igt) (Max)
200 mA
Current - On State (It (AV)) (Max)
1473 A
Voltage - Gate Trigger (Vgt) (Max)
3 V
Current - On State (It (RMS)) (Max)
2913 A
Current - Non Rep. Surge 50, 60Hz (Itsm)
20A, 21.2A
| Attribute | Value |
|---|---|
| SCR Type | Standard Recovery |
| Packaging | Bulk |
| Part Status | Obsolete |
| Manufacturer | Vishay General Semiconductor - Diodes Division |
| Mounting Type | Clamp On |
| Package / Case | TO-200AC, K-PUK, A-24 |
| Base Product Number | ST1000 |
| Voltage - Off State | 2.2 kV |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | A-24 (K-Puk) |
| Current - Hold (Ih) (Max) | 600 mA |
| Current - Off State (Max) | 100 mA |
| Voltage - On State (Vtm) (Max) | 1.8 V |
| Current - Gate Trigger (Igt) (Max) | 200 mA |
| Current - On State (It (AV)) (Max) | 1473 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Current - On State (It (RMS)) (Max) | 2913 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 20A, 21.2A |
