Step1: Product
UMW LM317DCYR
Image shown is a representation only
Manufacturer
Manufacturer No
LM317DCYR
Package
TO-261-4, TO-261AA
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC REG LIN POS ADJ 1.5A SOT-223
Detailed Description
Linear Voltage Regulator IC Positive Adjustable 1 Output 1.5A SOT-223
DataSheet
Mfr
UMW
PSRR
75dB ~ 60dB (120Hz)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Output Type
Adjustable
Part Status
Active
Mounting Type
Surface Mount
Package / Case
TO-261-4, TO-261AA
Current - Output
1.5A
Protection Features
Over Current, Over Temperature, Short Circuit
Number of Regulators
1
Output Configuration
Positive
Operating Temperature
0°C ~ 125°C (TJ)
Voltage - Input (Max)
40V
Voltage - Output (Max)
37V
Supplier Device Package
SOT-223
Current - Quiescent (Iq)
12 mA
Voltage - Output (Min/Fixed)
1.2V
| Attribute | Value |
|---|---|
| Mfr | UMW |
| PSRR | 75dB ~ 60dB (120Hz) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Output Type | Adjustable |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-4, TO-261AA |
| Current - Output | 1.5A |
| Protection Features | Over Current, Over Temperature, Short Circuit |
| Number of Regulators | 1 |
| Output Configuration | Positive |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Voltage - Input (Max) | 40V |
| Voltage - Output (Max) | 37V |
| Supplier Device Package | SOT-223 |
| Current - Quiescent (Iq) | 12 mA |
| Voltage - Output (Min/Fixed) | 1.2V |
