Step1: Product
Triad Magnetics CSE187L-B
Image shown is a representation only
Manufacturer
Manufacturer No
CSE187L-B
Packaging
Bulk
Description
CURR SENSE XFMR 1:500 TH
Detailed Description
1:500 Current Sense Transformer 250mOhm Max Through Hole
DataSheet
Series
CSE187
Packaging
Bulk
Part Status
Active
Manufacturer
Triad Magnetics
Mounting Type
Through Hole
Size / Dimension
0.875" L x 0.875" W (22.23mm x 22.23mm)
Termination Style
PC Pin
DC Resistance (DCR)
250mOhm Max
Height - Seated (Max)
0.720" (18.29mm)
Turns Ratio - Primary:Secondary
1:500
| Attribute | Value |
|---|---|
| Series | CSE187 |
| Packaging | Bulk |
| Part Status | Active |
| Manufacturer | Triad Magnetics |
| Mounting Type | Through Hole |
| Size / Dimension | 0.875" L x 0.875" W (22.23mm x 22.23mm) |
| Termination Style | PC Pin |
| DC Resistance (DCR) | 250mOhm Max |
| Height - Seated (Max) | 0.720" (18.29mm) |
| Turns Ratio - Primary:Secondary | 1:500 |
