Step1: Product
Toshiba Semiconductor and Storage TLP3043(S,C,F)
Image shown is a representation only
Manufacturer
Manufacturer No
TLP3043(S,C,F)
Package
6-DIP (0.300", 7.62mm), 5 Leads
Packaging
Tube
Description
OPTOISOLATOR 5KV TRIAC 1CH 6DIP
Detailed Description
Optoisolator Triac Output 5000Vrms 1 Channel 6-DIP (Cut), 5 Lead
DataSheet
Packaging
Tube
Output Type
Triac
Part Status
Obsolete
Manufacturer
Toshiba Semiconductor and Storage
Mounting Type
Through Hole
Package / Case
6-DIP (0.300", 7.62mm), 5 Leads
Approval Agency
BSI, SEMKO, UR
Number of Channels
1
Static dV/dt (Min)
200V/µs
Base Product Number
TLP3043
Current - Hold (Ih)
600µA (Typ)
Voltage - Isolation
5000Vrms
Voltage - Off State
400 V
Operating Temperature
-40°C ~ 100°C
Zero Crossing Circuit
Yes
Supplier Device Package
6-DIP (Cut), 5 Lead
Voltage - Forward (Vf) (Typ)
1.15V
Current - DC Forward (If) (Max)
50 mA
Current - LED Trigger (Ift) (Max)
5mA
Current - On State (It (RMS)) (Max)
100 mA
| Attribute | Value |
|---|---|
| Packaging | Tube |
| Output Type | Triac |
| Part Status | Obsolete |
| Manufacturer | Toshiba Semiconductor and Storage |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP (0.300", 7.62mm), 5 Leads |
| Approval Agency | BSI, SEMKO, UR |
| Number of Channels | 1 |
| Static dV/dt (Min) | 200V/µs |
| Base Product Number | TLP3043 |
| Current - Hold (Ih) | 600µA (Typ) |
| Voltage - Isolation | 5000Vrms |
| Voltage - Off State | 400 V |
| Operating Temperature | -40°C ~ 100°C |
| Zero Crossing Circuit | Yes |
| Supplier Device Package | 6-DIP (Cut), 5 Lead |
| Voltage - Forward (Vf) (Typ) | 1.15V |
| Current - DC Forward (If) (Max) | 50 mA |
| Current - LED Trigger (Ift) (Max) | 5mA |
| Current - On State (It (RMS)) (Max) | 100 mA |
