Toshiba Semiconductor and Storage TB67S109AFNG,EL
Image shown is a representation only
Manufacturer
Manufacturer No
TB67S109AFNG,EL
Quantity
88
Availability
In Stock
Package
48-TFSOP (0.240", 6.10mm Width) Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC MOTOR DRIVER BIPOLAR 48HTSSOP
Detailed Description
Bipolar Motor Driver Power MOSFET Parallel 48-HTSSOP
DataSheet
Function
Driver - Fully Integrated, Control and Power Stage
Interface
Parallel
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
Power MOSFET
Part Status
Active
Applications
General Purpose
Manufacturer
Toshiba Semiconductor and Storage
Mounting Type
Surface Mount
Package / Case
48-TFSOP (0.240", 6.10mm Width) Exposed Pad
Voltage - Load
10V ~ 47V
Step Resolution
1 ~ 1/32
Current - Output
3A
Voltage - Supply
4.75V ~ 5.25V
Base Product Number
TB67S109
Motor Type - Stepper
Bipolar
Output Configuration
Half Bridge (4)
Operating Temperature
-20°C ~ 150°C (TJ)
Supplier Device Package
48-HTSSOP
| Attribute | Value |
|---|---|
| Function | Driver - Fully Integrated, Control and Power Stage |
| Interface | Parallel |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | Power MOSFET |
| Part Status | Active |
| Applications | General Purpose |
| Manufacturer | Toshiba Semiconductor and Storage |
| Mounting Type | Surface Mount |
| Package / Case | 48-TFSOP (0.240", 6.10mm Width) Exposed Pad |
| Voltage - Load | 10V ~ 47V |
| Step Resolution | 1 ~ 1/32 |
| Current - Output | 3A |
| Voltage - Supply | 4.75V ~ 5.25V |
| Base Product Number | TB67S109 |
| Motor Type - Stepper | Bipolar |
| Output Configuration | Half Bridge (4) |
| Operating Temperature | -20°C ~ 150°C (TJ) |
| Supplier Device Package | 48-HTSSOP |
