Step1: Product
Toshiba Semiconductor and Storage DF2B7AE,L3F
Image shown is a representation only
Manufacturer
Manufacturer No
DF2B7AE,L3F
Date Code
22+
Quantity
3,650
Availability
In Stock
Package
SC-79, SOD-523
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
TVS DIODE 5.5VWM 20VC ESC
Detailed Description
20V Clamp 4A (8/20µs) Ipp Tvs Diode Surface Mount ESC
Datasheet
Mfr
Toshiba Semiconductor and Storage
Type
Zener
Packaging
Tape & Reel (TR); Cut Tape (CT)
Applications
General Purpose
Mounting Type
Surface Mount
Package / Case
SC-79, SOD-523
Power - Peak Pulse
80W
Base Product Number
DF2B7
Operating Temperature
150°C (TJ)
Power Line Protection
No
Bidirectional Channels
1
Capacitance @ Frequency
8.5pF @ 1MHz
Supplier Device Package
ESC
Voltage - Breakdown (Min)
5.8V
Voltage - Clamping (Max) @ Ipp
20V
Voltage - Reverse Standoff (Typ)
5.5V (Max)
Current - Peak Pulse (10/1000µs)
4A (8/20µs)
| Attribute | Value |
|---|---|
| Mfr | Toshiba Semiconductor and Storage |
| Type | Zener |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Applications | General Purpose |
| Mounting Type | Surface Mount |
| Package / Case | SC-79, SOD-523 |
| Power - Peak Pulse | 80W |
| Base Product Number | DF2B7 |
| Operating Temperature | 150°C (TJ) |
| Power Line Protection | No |
| Bidirectional Channels | 1 |
| Capacitance @ Frequency | 8.5pF @ 1MHz |
| Supplier Device Package | ESC |
| Voltage - Breakdown (Min) | 5.8V |
| Voltage - Clamping (Max) @ Ipp | 20V |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Current - Peak Pulse (10/1000µs) | 4A (8/20µs) |
