Texas Instruments TPSI2240CQDWQRQ1
Image shown is a representation only
Manufacturer
Manufacturer No
TPSI2240CQDWQRQ1
Package
11-SOIC (0.295", 7.50mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
AUTOMOTIVE 1200V, 50MA ISOLATED
Detailed Description
Solid State Photo-Coupled Relay (Photorelay) DPST-NO/NC (1 Form A and B) 11-SOIC (0.295", 7.50mm Width)
DataSheet
Mfr
Texas Instruments
Grade
Automotive
Circuit
DPST-NO/NC (1 Form A and B)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Relay Type
Photo-Coupled Relay (Photorelay)
Output Type
DC
Part Status
Active
Load Current
50 mA
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
11-SOIC (0.295", 7.50mm Width)
Voltage - Load
0 V ~ 1200 V
Approval Agency
UL, VDE
Voltage - Input
4.5 ~ 20VDC
Operating Temperature
-40°C ~ 125°C
Supplier Device Package
11-SOIC
On-State Resistance (Max)
300 Ohms
| Attribute | Value |
|---|---|
| Mfr | Texas Instruments |
| Grade | Automotive |
| Circuit | DPST-NO/NC (1 Form A and B) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Relay Type | Photo-Coupled Relay (Photorelay) |
| Output Type | DC |
| Part Status | Active |
| Load Current | 50 mA |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 11-SOIC (0.295", 7.50mm Width) |
| Voltage - Load | 0 V ~ 1200 V |
| Approval Agency | UL, VDE |
| Voltage - Input | 4.5 ~ 20VDC |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 11-SOIC |
| On-State Resistance (Max) | 300 Ohms |
