Step1: Product
TE Connectivity Potter & Brumfield Relays 9100-233Q999
Image shown is a representation only
Manufacturer
Manufacturer No
9100-233Q999
Packaging
Bulk
Description
RELAY GEN PURPOSE SPDT 15A 24V
Detailed Description
General Purpose Relay SPDT (1 Form C) 24VAC Coil Chassis Mount
DataSheet
Mfr
TE Connectivity Potter & Brumfield Relays
Series
9100, Products Unlimited
Coil Type
Non Latching
Packaging
Bulk
Relay Type
General Purpose
Part Status
Obsolete
Coil Voltage
24VAC
Contact Form
SPDT (1 Form C)
Mounting Type
Chassis Mount
Approval Agency
cURus
Coil Insulation
Class B
Contact Material
Silver (Ag)
Switching Voltage
277VAC - Max
Termination Style
Quick Connect - 0.250" (6.3mm)
Base Product Number
233Q999
Load - Max Switching
4155VA
Must Operate Voltage
20.4 VAC
Operating Temperature
-40°C ~ 65°C
Contact Rating (Current)
15 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Series | 9100, Products Unlimited |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Part Status | Obsolete |
| Coil Voltage | 24VAC |
| Contact Form | SPDT (1 Form C) |
| Mounting Type | Chassis Mount |
| Approval Agency | cURus |
| Coil Insulation | Class B |
| Contact Material | Silver (Ag) |
| Switching Voltage | 277VAC - Max |
| Termination Style | Quick Connect - 0.250" (6.3mm) |
| Base Product Number | 233Q999 |
| Load - Max Switching | 4155VA |
| Must Operate Voltage | 20.4 VAC |
| Operating Temperature | -40°C ~ 65°C |
| Contact Rating (Current) | 15 A |
