Step1: Product
TE Connectivity Potter & Brumfield Relays 3-1904022-2
Image shown is a representation only
Manufacturer
Manufacturer No
3-1904022-2
Packaging
Bulk
Description
RELAY GEN PURPOSE SPDT 30A 12V
Detailed Description
General Purpose Relay SPDT (1 Form C) 12VDC Coil Chassis Mount
DataSheet
Mfr
TE Connectivity Potter & Brumfield Relays
Series
V23234, AXICOM
Coil Type
Non Latching
Packaging
Bulk
Relay Type
General Purpose
Part Status
Obsolete
Coil Current
16.7 mA
Coil Voltage
12VDC
Contact Form
SPDT (1 Form C)
Operate Time
7 ms
Release Time
2 ms
Mounting Type
Chassis Mount
Coil Resistance
85 Ohms
Contact Material
Silver Alloy
Switching Voltage
12VDC - Nom
Termination Style
Quick Connect - 0.187"/0.250"
Base Product Number
V23234
Must Operate Voltage
8 VDC
Must Release Voltage
1.5 VDC
Operating Temperature
-40°C ~ 105°C
Contact Rating (Current)
30 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Series | V23234, AXICOM |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Part Status | Obsolete |
| Coil Current | 16.7 mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 7 ms |
| Release Time | 2 ms |
| Mounting Type | Chassis Mount |
| Coil Resistance | 85 Ohms |
| Contact Material | Silver Alloy |
| Switching Voltage | 12VDC - Nom |
| Termination Style | Quick Connect - 0.187"/0.250" |
| Base Product Number | V23234 |
| Must Operate Voltage | 8 VDC |
| Must Release Voltage | 1.5 VDC |
| Operating Temperature | -40°C ~ 105°C |
| Contact Rating (Current) | 30 A |
