Step1: Product
TE Connectivity Potter & Brumfield Relays 1432826-1
Image shown is a representation only
Manufacturer
Manufacturer No
1432826-1
Packaging
Bulk
Description
RELAY GEN PURPOSE SPDT 30A 24V
Detailed Description
General Purpose Relay SPDT (1 Form C) 24VDC Coil Socketable
DataSheet
Mfr
TE Connectivity Potter & Brumfield Relays
Series
VF4
Coil Type
Non Latching
Packaging
Bulk
Relay Type
General Purpose
Part Status
Obsolete
Coil Current
66.7 mA
Coil Voltage
24VDC
Contact Form
SPDT (1 Form C)
Operate Time
8 ms
Release Time
5 ms
Mounting Type
Socketable
Coil Resistance
360 Ohms
Contact Material
Silver Tin Oxide (AgSnO)
Switching Voltage
14VDC - Nom
Termination Style
Plug In, Quick Connect - 0.250" (6.3mm)
Base Product Number
1432826
Must Operate Voltage
15.6 VDC
Must Release Voltage
2.4 VDC
Operating Temperature
-40°C ~ 85°C
Contact Rating (Current)
30 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Series | VF4 |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Part Status | Obsolete |
| Coil Current | 66.7 mA |
| Coil Voltage | 24VDC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 8 ms |
| Release Time | 5 ms |
| Mounting Type | Socketable |
| Coil Resistance | 360 Ohms |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Switching Voltage | 14VDC - Nom |
| Termination Style | Plug In, Quick Connect - 0.250" (6.3mm) |
| Base Product Number | 1432826 |
| Must Operate Voltage | 15.6 VDC |
| Must Release Voltage | 2.4 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 30 A |
