Step1: Product
TE Connectivity Potter & Brumfield Relays 1-1956024-0
Image shown is a representation only
Manufacturer
Manufacturer No
1-1956024-0
Packaging
Tube
Description
V23092-S1005-A301
Detailed Description
General Purpose Relay SPDT (1 Form C) 5VDC Coil Socketable
DataSheet
Mfr
TE Connectivity Potter & Brumfield Relays
Series
V23092, AXICOM
Coil Type
Non Latching
Packaging
Tube
Relay Type
General Purpose
Part Status
Active
Coil Current
34 mA
Coil Voltage
5VDC
Contact Form
SPDT (1 Form C)
Operate Time
12 ms
Release Time
5 ms
Mounting Type
Socketable
Approval Agency
cURus, VDE
Coil Resistance
147 Ohms
Contact Material
Silver Cadmium Oxide (AgCdO), Gold (Au)
Switching Voltage
400VAC - Max
Termination Style
Plug In
Base Product Number
V23092
Load - Max Switching
2400VA
Must Operate Voltage
3.5 VDC
Must Release Voltage
0.25 VDC
Operating Temperature
-40°C ~ 85°C
Contact Rating (Current)
6 A
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Series | V23092, AXICOM |
| Coil Type | Non Latching |
| Packaging | Tube |
| Relay Type | General Purpose |
| Part Status | Active |
| Coil Current | 34 mA |
| Coil Voltage | 5VDC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 12 ms |
| Release Time | 5 ms |
| Mounting Type | Socketable |
| Approval Agency | cURus, VDE |
| Coil Resistance | 147 Ohms |
| Contact Material | Silver Cadmium Oxide (AgCdO), Gold (Au) |
| Switching Voltage | 400VAC - Max |
| Termination Style | Plug In |
| Base Product Number | V23092 |
| Load - Max Switching | 2400VA |
| Must Operate Voltage | 3.5 VDC |
| Must Release Voltage | 0.25 VDC |
| Operating Temperature | -40°C ~ 85°C |
| Contact Rating (Current) | 6 A |
