Step1: Product
TE Connectivity Passive Product 3-1676906-8
Image shown is a representation only
Manufacturer
Manufacturer No
3-1676906-8
Package
0805 (2012 Metric)
Packaging
Tape & Reel (TR)
Description
CAP TANT 0.047UF 20% 25V 0805
Detailed Description
0.047 µF Molded Tantalum Capacitors 25 V 0805 (2012 Metric)
DataSheet
Mfr
TE Connectivity Passive Product
Type
Molded
Series
TYTP
Features
General Purpose
Packaging
Tape & Reel (TR)
Tolerance
±20%
Capacitance
0.047 µF
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
0805 (2012 Metric)
Voltage - Rated
25 V
Size / Dimension
0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max)
0.055" (1.40mm)
Operating Temperature
-55°C ~ 125°C
Manufacturer Size Code
P
| Attribute | Value |
|---|---|
| Mfr | TE Connectivity Passive Product |
| Type | Molded |
| Series | TYTP |
| Features | General Purpose |
| Packaging | Tape & Reel (TR) |
| Tolerance | ±20% |
| Capacitance | 0.047 µF |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric) |
| Voltage - Rated | 25 V |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height - Seated (Max) | 0.055" (1.40mm) |
| Operating Temperature | -55°C ~ 125°C |
| Manufacturer Size Code | P |
