Step1: Product
TE Connectivity AMP Connectors 3-1571552-2
Image shown is a representation only
Manufacturer
Manufacturer No
3-1571552-2
Quantity
45
Availability
In Stock
Packaging
Tube
Description
840-AG11D-ESL-LF=800 DIP GF/SN
Detailed Description
40 Pos DIP, 0.6" (15.24mm) Row Spacing Socket Gold Through Hole
Type
DIP, 0.6" (15.24mm) Row Spacing
Series
800
Features
Open Frame
Packaging
Tube
Part Status
Active
Termination
Solder
Manufacturer
TE Connectivity AMP Connectors
Pitch - Post
0.100" (2.54mm)
Mounting Type
Through Hole
Pitch - Mating
0.100" (2.54mm)
Housing Material
Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
Contact Resistance
10mOhm
Contact Finish - Post
Gold
Current Rating (Amps)
3 A
Operating Temperature
-55°C ~ 105°C
Contact Finish - Mating
Gold
Contact Material - Post
Copper
Termination Post Length
0.125" (3.18mm)
Contact Material - Mating
Beryllium Copper
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
Flash
Contact Finish Thickness - Mating
Flash
Number of Positions or Pins (Grid)
40
| Attribute | Value |
|---|---|
| Type | DIP, 0.6" (15.24mm) Row Spacing |
| Series | 800 |
| Features | Open Frame |
| Packaging | Tube |
| Part Status | Active |
| Termination | Solder |
| Manufacturer | TE Connectivity AMP Connectors |
| Pitch - Post | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Pitch - Mating | 0.100" (2.54mm) |
| Housing Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester |
| Contact Resistance | 10mOhm |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 3 A |
| Operating Temperature | -55°C ~ 105°C |
| Contact Finish - Mating | Gold |
| Contact Material - Post | Copper |
| Termination Post Length | 0.125" (3.18mm) |
| Contact Material - Mating | Beryllium Copper |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | Flash |
| Number of Positions or Pins (Grid) | 40 |
