Step1: Product
TE Connectivity AMP Connectors 1933396-2
Image shown is a representation only
Manufacturer
Manufacturer No
1933396-2
Packaging
Bulk
Description
AC RCPT NEMA 5-20R
Detailed Description
Power Connector Receptacle, Female Sockets NEMA 5-20R Outlet Box
DataSheet
Packaging
Bulk
Part Status
Obsolete
Termination
Screw
Manufacturer
TE Connectivity AMP Connectors
Mounting Type
Outlet Box
Connector Type
Receptacle, Female Sockets
Voltage Rating
125VAC
Connector Style
NEMA 5-20R
Base Product Number
1933396
Number of Positions
3 per connection (2)
Current Rating (Amps)
20A
Panel Cutout Dimensions
Rectangular - 41.78mm x 66.29mm
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Part Status | Obsolete |
| Termination | Screw |
| Manufacturer | TE Connectivity AMP Connectors |
| Mounting Type | Outlet Box |
| Connector Type | Receptacle, Female Sockets |
| Voltage Rating | 125VAC |
| Connector Style | NEMA 5-20R |
| Base Product Number | 1933396 |
| Number of Positions | 3 per connection (2) |
| Current Rating (Amps) | 20A |
| Panel Cutout Dimensions | Rectangular - 41.78mm x 66.29mm |
| Material Flammability Rating | UL94 V-0 |
