Step1: Product
TE Connectivity AMP Connectors 1527272-3
Image shown is a representation only
Manufacturer
Manufacturer No
1527272-3
Packaging
Box
Description
CONN TERM RECT RING 8 AWG #10
Detailed Description
Terminal Connector Rectangular Ring, Tubular 8 AWG 10 Stud
DataSheet
Color
Red
Features
Heavy Duty
Packaging
Box
Insulation
Non-Insulated
Wire Gauge
8 AWG
Part Status
Obsolete
Termination
Crimp, Barrel
Manufacturer
TE Connectivity AMP Connectors
Mounting Type
Free Hanging (In-Line)
Stud/Tab Size
10 Stud
Tab Thickness
0.078" (1.98mm)
Terminal Type
Ring, Tubular
Contact Finish
Tin
Terminal Style
Two Stud Holes
Contact Material
Copper
Length - Overall
1.740" (44.20mm)
Diameter - Ring ID
0.212" (5.38mm)
Base Product Number
1527272
Width - Outer Edges
0.350" (8.89mm)
Diameter - Barrel ID
0.170" (4.32mm)
Diameter - Barrel OD
0.248" (6.30mm)
| Attribute | Value |
|---|---|
| Color | Red |
| Features | Heavy Duty |
| Packaging | Box |
| Insulation | Non-Insulated |
| Wire Gauge | 8 AWG |
| Part Status | Obsolete |
| Termination | Crimp, Barrel |
| Manufacturer | TE Connectivity AMP Connectors |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 10 Stud |
| Tab Thickness | 0.078" (1.98mm) |
| Terminal Type | Ring, Tubular |
| Contact Finish | Tin |
| Terminal Style | Two Stud Holes |
| Contact Material | Copper |
| Length - Overall | 1.740" (44.20mm) |
| Diameter - Ring ID | 0.212" (5.38mm) |
| Base Product Number | 1527272 |
| Width - Outer Edges | 0.350" (8.89mm) |
| Diameter - Barrel ID | 0.170" (4.32mm) |
| Diameter - Barrel OD | 0.248" (6.30mm) |
