Step1: Product
TE Connectivity AMP Connectors 1393315-2
Image shown is a representation only
Manufacturer
Manufacturer No
1393315-2
Quantity
6
Availability
In Stock
Packaging
Bulk
Description
RELAY AUTO SPST-NO 130A 12V
Detailed Description
Automotive Relay SPST-NO (1 Form A) 12VDC Coil Chassis Mount
DataSheet
Series
HCR 150
Coil Type
Non Latching
Packaging
Bulk
Coil Power
3.9W
Part Status
Active
Coil Voltage
12VDC
Contact Form
SPST-NO (1 Form A)
Manufacturer
TE Connectivity AMP Connectors
Operate Time
25 ms
Release Time
8 ms
Mounting Type
Chassis Mount
Coil Resistance
37 Ohms
Contact Material
Silver Tin Oxide (AgSnO)
Switching Voltage
12VDC - Nom
Termination Style
Screw Terminal
Base Product Number
1393315
Must Operate Voltage
7.2 VDC
Must Release Voltage
1.2 VDC
Operating Temperature
-40°C ~ 125°C
Contact Rating (Current)
130 A
| Attribute | Value |
|---|---|
| Series | HCR 150 |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Coil Power | 3.9W |
| Part Status | Active |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Manufacturer | TE Connectivity AMP Connectors |
| Operate Time | 25 ms |
| Release Time | 8 ms |
| Mounting Type | Chassis Mount |
| Coil Resistance | 37 Ohms |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Switching Voltage | 12VDC - Nom |
| Termination Style | Screw Terminal |
| Base Product Number | 1393315 |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.2 VDC |
| Operating Temperature | -40°C ~ 125°C |
| Contact Rating (Current) | 130 A |
