Step1: Product
TE Connectivity AMP Connectors 1-6610155-2
Image shown is a representation only
Manufacturer
Manufacturer No
1-6610155-2
Packaging
Tray
Description
CONN JACK 4PORT PCB
Detailed Description
4 Port RJ45 Through Hole 10/100/1000 Base-T, AutoMDIX
DataSheet
Series
Mag45
Features
Board Lock
LED Color
Green - Orange
Packaging
Tray
Shielding
Shielded, EMI Finger
Orientation
90° Angle (Right)
Part Status
Obsolete
Termination
Solder
Applications
10/100/1000 Base-T, AutoMDIX
Manufacturer
TE Connectivity AMP Connectors
Mounting Type
Through Hole
Tab Direction
Up
Connector Type
RJ45
Contact Finish
Gold
Number of Rows
1
Number of Ports
4
Shield Material
Brass
Contact Material
Phosphor Bronze
Housing Material
Polyethylene Terephthalate (PET), Polyester
Height Above Board
0.555" (14.10mm)
Base Product Number
6610155
Operating Temperature
0°C ~ 70°C
Contact Finish Thickness
50.0µin (1.27µm)
Number of Cores per Jack
12
| Attribute | Value |
|---|---|
| Series | Mag45 |
| Features | Board Lock |
| LED Color | Green - Orange |
| Packaging | Tray |
| Shielding | Shielded, EMI Finger |
| Orientation | 90° Angle (Right) |
| Part Status | Obsolete |
| Termination | Solder |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Manufacturer | TE Connectivity AMP Connectors |
| Mounting Type | Through Hole |
| Tab Direction | Up |
| Connector Type | RJ45 |
| Contact Finish | Gold |
| Number of Rows | 1 |
| Number of Ports | 4 |
| Shield Material | Brass |
| Contact Material | Phosphor Bronze |
| Housing Material | Polyethylene Terephthalate (PET), Polyester |
| Height Above Board | 0.555" (14.10mm) |
| Base Product Number | 6610155 |
| Operating Temperature | 0°C ~ 70°C |
| Contact Finish Thickness | 50.0µin (1.27µm) |
| Number of Cores per Jack | 12 |
