Step1: Product
SURGE HS2GA
Image shown is a representation only
Manufacturer
Manufacturer No
HS2GA
Package
DO-214AC, SMA
Packaging
Bag
Description
DIODE STANDARD 400V 1.5A DO214AC
Detailed Description
Diode 400 V 1.5A Surface Mount DO-214AC (SMA)
DataSheet
Mfr
SURGE
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Series
HS2
Packaging
Bag
Technology
Standard
Part Status
Active
Mounting Type
Surface Mount
Package / Case
DO-214AC, SMA
Capacitance @ Vr, F
50pF @ 4V, 1MHz
Supplier Device Package
DO-214AC (SMA)
Reverse Recovery Time (trr)
50 ns
Current - Reverse Leakage @ Vr
5 µA @ 400 V
Voltage - DC Reverse (Vr) (Max)
400 V
Current - Average Rectified (Io)
1.5A
Operating Temperature - Junction
-55°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If
1.3 V @ 1.5 A
| Attribute | Value |
|---|---|
| Mfr | SURGE |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Series | HS2 |
| Packaging | Bag |
| Technology | Standard |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | DO-214AC, SMA |
| Capacitance @ Vr, F | 50pF @ 4V, 1MHz |
| Supplier Device Package | DO-214AC (SMA) |
| Reverse Recovery Time (trr) | 50 ns |
| Current - Reverse Leakage @ Vr | 5 µA @ 400 V |
| Voltage - DC Reverse (Vr) (Max) | 400 V |
| Current - Average Rectified (Io) | 1.5A |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1.3 V @ 1.5 A |
