Step1: Product
STMicroelectronics STOD1412PMR
Image shown is a representation only
Manufacturer
Manufacturer No
STOD1412PMR
Package
16-WFQFN Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC REG BOOST ADJ 900MA DL 16QFN
Detailed Description
Boost Switching Regulator IC Positive and Negative (Dual Rail) Adjustable 4.3V, -2V 2 Output 900mA (Switch) 16-WFQFN Exposed Pad
DataSheet
Mfr
STMicroelectronics
Function
Step-Up
Topology
Boost
Packaging
Tape & Reel (TR)
Output Type
Adjustable
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
16-WFQFN Exposed Pad
Current - Output
900mA (Switch)
Number of Outputs
2
Base Product Number
STOD14
Output Configuration
Positive and Negative (Dual Rail)
Frequency - Switching
1.3MHz
Operating Temperature
-40°C ~ 85°C (TJ)
Synchronous Rectifier
Yes
Voltage - Input (Max)
5.5V
Voltage - Input (Min)
2.7V
Voltage - Output (Max)
6V, -8V
Supplier Device Package
16-QFN (3x3)
Voltage - Output (Min/Fixed)
4.3V, -2V
| Attribute | Value |
|---|---|
| Mfr | STMicroelectronics |
| Function | Step-Up |
| Topology | Boost |
| Packaging | Tape & Reel (TR) |
| Output Type | Adjustable |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 16-WFQFN Exposed Pad |
| Current - Output | 900mA (Switch) |
| Number of Outputs | 2 |
| Base Product Number | STOD14 |
| Output Configuration | Positive and Negative (Dual Rail) |
| Frequency - Switching | 1.3MHz |
| Operating Temperature | -40°C ~ 85°C (TJ) |
| Synchronous Rectifier | Yes |
| Voltage - Input (Max) | 5.5V |
| Voltage - Input (Min) | 2.7V |
| Voltage - Output (Max) | 6V, -8V |
| Supplier Device Package | 16-QFN (3x3) |
| Voltage - Output (Min/Fixed) | 4.3V, -2V |
